150℃ 1000V/1500V XLPO High Voltage No Shielding EV Cable
-
150℃ 1000V/1500V
-
Zhongxin
-
85444921
| Quantity: | |
|---|---|
Product Description
Product Description
Product Advantages
- High-Temperature Resistance: Rated for operation in extreme temperatures, from -40℃ to +125℃/+150℃, making it suitable for various environmental conditions.
- Flame Retardancy: Certified to pass the Single Vertical Combustion test, ensuring enhanced fire safety.
- Compliance with Standards: Adheres to ISO 6722-2011, GB/T 25085, QC/T 1037-2016, DEKRA K179, and CQC1122 standards, guaranteeing reliability and quality.
- Versatile Conductor Options: Available in soft or tin-coated annealed copper wire, IEC60228/VDE0295 Class 5 or Class 6, providing flexibility for various system designs.
Technical Features
- Voltage Test: The cable undergoes a 5000V voltage test to ensure its safety and reliability.
- Insulation Resistance: The insulation resistance is ≥1010 Ω.mm, providing excellent electrical insulation.
- Excellent Flexibility: The cable is highly flexible, making it easy to install in tight spaces.
- Environmental Resistance: The cable is resistant to heat, cold, fluids, oil, ultraviolet light, and ozone, ensuring long-term performance in harsh conditions.
- Conductor Performance: The cable features excellent conductivity and low-temperature performance, meeting the needs of both general passenger cars and high-power vehicles such as commercial vehicles and buses.
- Compliance: The cable meets ROHS, REACH, and VOC standards, ensuring environmental safety.
Applications
- Electric Vehicles (EVs): Ideal for connecting high-voltage components in EVs, such as batteries, motors, and inverters.
- Charging Stations: Suitable for internal wiring of charging stations, ensuring reliable power transmission.
- Renewable Energy Systems: Enhances safety and efficiency in solar and wind energy systems, contributing to sustainable energy management.
- Industrial Equipment: Suitable for internal wiring of electronic and electrical equipment, ensuring stable and reliable connections.
Transportation & Storage
- Packaging: The cable is supplied in coils with protective wrapping to prevent damage during transit.
- Handling: Designed for easy loading and unloading; avoid sharp bends or excessive tension to maintain cable integrity.
- Storage: Store in a dry, ventilated environment away from direct sunlight and corrosive substances to ensure long-term performance.
Specifications
| Parameter | Details |
|---|---|
| Temperature Rating | -40℃ to +125℃/+150℃ |
| Voltage Rating | AC600V/DC900V or AC1000V/DC1500V |
| Minimum Bending Radius | 5D (D: Outer Diameter) |
| Conductor | Soft or Tin-coated Annealed Copper Wire, IEC60228/VDE0295 Class 5 or Class 6 |
| Insulation Material | Cross-linked Elastomer or XLPO |
| Color | Orange or Optional |
| Standards | ISO 6722-2011, GB/T 25085, QC/T 1037-2016, DEKRA K179, CQC1122, ROHS, REACH, VOC |
Customer Reviews
- "Reliable and Safe" – Engineer at an EV Manufacturer: "The 150°C 1000V/1500V XLPO cable’s high-temperature resistance and flame retardancy have made our installations safer and more efficient."
- "Durable and Easy to Install" – Technician at a Charging Station Project: "The cable’s flexibility and robust construction saved us time during setup. It’s a top choice for high-voltage EV systems."
Conclusion
Performance Parameter
额定电压 Rating Volt. | 规格 mm2 | 导体结构 No./mm | 导体外径 Conductor Dia. (mm) | 绝缘厚度 Insulation Nom. Thickness (mm) | 绝缘外径 Insulation Nom. Dia. (mm) | 导体电阻 Conductor Resistance (Ω/km,20℃) | 参考电流 Reference current |
1000V/1500V | 1.5 | 48/0.20 | 1.60 | 0.6 | 2.90 | 12.70 | 26A |
2.5 | 79/0.20 | 2.05 | 0.7 | 3.50 | 7.60 | 35A | |
4 | 133/0.20 | 2.85 | 0.8 | 4.20 | 4.71 | 41A | |
6 | 189/0.20 | 3.40 | 0.8 | 4.90 | 3.14 | 62A | |
10 | 322/0.20 | 4.50 | 1.0 | 6.30 | 1.82 | 91A | |
16 | 513/0.20 | 5.60 | 1.0 | 7.80 | 1.16 | 123A | |
25 | 798/0.20 | 7.00 | 1.3 | 9.90 | 0.743 | 160A | |
35 | 1121/0.20 | 8.40 | 1.3 | 11.20 | 0.527 | 205A | |
50 | 1596/0.20 | 10.0 | 1.5 | 13.20 | 0.368 | 250A | |
70 | 2257/0.20 | 11.9 | 1.5 | 15.20 | 0.259 | 300A | |
95 | 3034/0.20 | 13.8 | 1.6 | 17.40 | 0.196 | 360A | |
120 | 3811/0.20 | 15.4 | 1.6 | 19.00 | 0.153 | 415A | |
150 | 3071/0.25 | 17.3 | 1.7 | 21.40 | 0.132 | 470A | |
185 | 3774/0.25 | 19.2 | 1.8 | 23.50 | 0.106 | 550A |
Product Advantage:
The 150℃ 1000V/1500V XLPO High Voltage No Shielding EV Cable is a high-quality cable specifically designed for electric vehicle applications. This cable offers excellent flexibility, allowing for easy bending and installation, making it convenient for various installation scenarios.
One of the key features of this cable is its resistance to combustion, as it has passed the single vertical combustion test, demonstrating its ability to withstand fire hazards. Additionally, it exhibits good delay combustibility, further enhancing its fire-resistant properties and ensuring safety in case of emergencies.
The cable is engineered to withstand a wide range of environmental conditions, including heat aging, thermal overload, low temperatures, exposure to fluids, oils, UV rays, ozone, and humidity. Its heating resistance, cold resistance, fluid resistance, oil resistance, ultraviolet resistance, ozone resistance, and weather resistance make it a durable and reliable solution for electric vehicle applications.
With superior conductivity and low conductor temperature rise, this cable not only meets the requirements of general passenger cars but also caters to the needs of high-power vehicles such as commercial vehicles, buses, and coaches. Its excellent conductivity ensures efficient power transmission while maintaining low temperatures for optimal performance.
Furthermore, the cable complies with environmental standards such as ROHS and REACH, ensuring low odor emissions and environmental sustainability. This cable is a top-notch choice for electric vehicle applications, offering safety, durability, and environmental compliance for a wide range of automotive needs.
Company Advantages
Established in 2001, the factory boasts over 20 years of experience in production management, ensuring a high level of expertise and efficiency.
The factory has a comprehensive management system in place, ensuring smooth operations and effective decision-making processes.
The workers at the factory have extensive production experience, contributing to the high quality and efficiency of the manufacturing process.
The factory holds various certificates, demonstrating its commitment to quality standards and compliance with regulations.
The factory offers a diverse range of products, catering to a wide range of customer needs and preferences.
Company Details
Wuxi Zhonghui Cable Co., Ltd. is located in Xishan District, Wuxi City, on the shore of the beautiful Taihu Lake. It is adjacent to Shanghai-Nanjing Expressway in the north, National Highway 312 in the south, and 30 kilometers away from Wuxi Airport. The geographical position is superior, with great accessibility. The company was founded in May 2001, covers an area of more than 15,000 square meters, has more than 120 employees, and has more than 50 million yuan in fixed assets. It is a professional research and development, production, and sales of wires, cables, plugs, and power cords of domestic enterprises.
The company mainly produces "Zhongxing" brand rubber flexible cords, motor lead wires, plug power cords, new energy vehicle cords, photovoltaic cords, wind energy cables, wind energy cables, energy storage cables, drag chain cables, and other special wires and cables. The products are widely used in electric power, water pumps, robot arm cables, household appliances, industrial automation, new energy vehicles, new energy power generation, construction, lifting machinery, power tools, and other industrial and civil fields.
The power cord certifications of various countries include: VDE, KEMA KEUR, NEMKO, DEMKO, FIMKO, SEMKO, S+, SAA, KC, SABS, S-Mark, GCC, INMETRO, GS, UL, ETL, ASTA, NF, CEBEC, etc.
FAQ
Q1: Are you a factory or trading company?
A1: We have 21 years of manufacturing experience
Q2: Which port is the nearest from you?
A2: Only 40 minutes from Shanghai by high-speed rail
Q3: What is your MOQ and sample term?
A3: Our MOQ is 1000pcs, we can offer you free samples, but you pls pay shipping costs.
