A Variety of PCB Terminal Blocks, Continuous Innovation in Connection Technology
Views: 0 Author: Site Editor Publish Time: 2024-11-11 Origin: Site
It is suitable for connecting the LED module on the back. The height of the module on the front of the PCB board is only 1.1 mm, which can greatly reduce the influence of its shadow on the LED and simplify the wiring work. It is an ideal choice for linear LED modules and ultra-flat lamps.
1. Brand new 2070 SMD PCB terminal block
It is suitable for connecting the LED module on the back. The height of the module on the front of the PCB board is only 1.1 mm, which can greatly reduce the influence of its shadow on the LED and simplify the wiring work. It is an ideal choice for linear LED modules and ultra-flat lamps.
2, the new 2065 series SMD terminal blocks
Without an insulating shell, the appearance is more compact and compact. This compact design not only greatly reduces the shadow on the PCB board, but also provides more free space for engineers to design LED modules and optical systems. In addition to standard LED and chip-on-board (COB) module applications, the advantages of the 2065 series make it not only applicable to lighting, but also to connect sensors and other devices, providing an alternative to hand-soldering wires in small spaces.
3, the new 2075 series through-hole board SMD PCB terminal block
is mainly used in vertically wired LED lamps. The appearance is compact and small, which can reduce the shadow of the connector in the lamp to a greater extent; it is suitable for one-time packaging process and is also suitable for industrial electronic applications requiring low height and vertical wiring. It is an economical way of saving costs for back wiring. selected.
4. PCB terminal blocks for new power electronic devices
The six products in this series can simplify high-current applications and are widely used in power supplies, frequency converters and servo drives. The eye-catching orange wrench design combines practicality and safety. All adopt straight-in cage spring connection technology, which is ideal for almost all applications. This full series of PCB terminal blocks are divided into two types with or without push buttons, which provides design engineers with flexibility when designing power electronic devices.
