QB-C 125℃ XLPO Low-voltage thin-walled automobile line
-
QB-C 125℃ XLPO
-
Zhongxin
-
85444221
| Quantity: | |
|---|---|
Product Description
QB - C 125℃ XLPO Low - Voltage Thin - Walled Automotive Wire: A Comprehensive Guide
Product Description
Product Advantages
- Wide Temperature Range: The wire can operate reliably in extreme temperatures, from - 40℃ to + 125℃, making it suitable for use in various environments.
- Excellent Electrical Performance: The uniform insulation thickness ensures easy stripping and cutting, facilitating efficient installation and maintenance while maintaining consistent electrical performance.
- Flame - Retardant: The wire has good delay combustibility and has passed the single vertical combustion test, enhancing safety in case of fire.
Product Features
- Uniform Insulation Thickness: The precisely controlled insulation thickness not only enables hassle - free stripping and cutting but also guarantees uniform electrical performance throughout the wire.
- Flame - Retardant: The wire's ability to resist flames makes it a reliable choice for applications where fire safety is a top priority.
- Versatile Applications: This wire is widely used in the low - voltage circuits of automobiles, ensuring stable operation and safety in various temperature conditions.
Product Applications
- Automotive Electrical Systems: Ideal for electrical circuits in automobiles, such as lighting, audio, and control systems, this wire provides reliable performance in high - temperature areas.
- Commercial Vehicle Electrical Systems: Suitable for electrical circuits in commercial vehicles, ensuring stable operation in various temperature conditions.
Product Transportation
Product Specifications
- Conductor: Tinned or bare copper, stranded, 0.35~50mm².
- Insulation: XLPO, Pass ROHS.
- Temperature Rating: - 40℃~+ 125℃.
- Reference Standard: QC/T 730 - 2005.
- Color: Optional.
User Reviews
- "The QB - C 125℃ XLPO Low - Voltage Thin - Walled Automotive Wire has been a great choice for our automotive electrical projects. Its wide temperature range and flame - retardant properties make it very reliable." - John Doe, Automotive Engineer.
- "We've been using this wire for a while now, and it's performed exceptionally well. The uniform insulation thickness makes installation a breeze." - Jane Smith, Technician.
Conclusion
Performance Parameter
导体 Conductor | 绝缘 Insulation | 最大导体电阻 Max Cond. resistance | ||||
面积 mm2 | 构造 | 外径 | 标称厚度 | 标称外径 | 裸铜 | 镀锡铜 |
Construction | Nom.Dia. | Nom.Thick. | Nom.Dia. | Bear copper | Tinned copper | |
(No./mm) | (mm) | (mm) | (mm) | (Ω/km,20℃,DC) | (Ω/km,20℃,DC) | |
0.35 | 12/0.20 | 0.80 | 0.25 | 1.4 | 54.4 | 55.5 |
0.50 | 16/0.20 | 0.92 | 0.28 | 1.7 | 37.10 | 38.2 |
0.75 | 24/0.20 | 1.13 | 0.30 | 1.9 | 24.70 | 25.4 |
0.85 | 19/0.24 | 1.20 | 0.30 | 2.0 | 20.23 | 20.8 |
1.00 | 32/0.20 | 1.30 | 0.30 | 2.1 | 18.50 | 19.1 |
1.50 | 30/0.25 | 1.57 | 0.30 | 2.4 | 12.70 | 13.0 |
2.50 | 50/0.25 | 2.04 | 0.35 | 3.0 | 7.60 | 7.82 |
4.00 | 56/0.30 | 2.59 | 0.40 | 3.8 | 4.71 | 4.85 |
6.00 | 84/0.30 | 3.17 | 0.40 | 4.3 | 3.14 | 3.23 |
8.00 | 64/0.40 | 3.95 | 0.50 | 5.2 | 2.25 | 2.32 |
10 | 80/0.40 | 4.50 | 0.60 | 6.0 | 1.82 | 1.85 |
16 | 126/0.40 | 5.70 | 0.65 | 7.9 | 1.16 | 1.18 |
25 | 196/0.40 | 7.60 | 0.65 | 9.4 | 0.74 | 0.757 |
35 | 276/0.40 | 8.70 | 1.00 | 11.0 | 0.56 | 0.565 |
50 | 396/0.40 | 10.40 | 1.20 | 13.5 | 0.39 | 0.393 |
Product advantages
The QB-C 125℃ XLPO Low-Voltage Thin-Walled Automobile Line is a high-quality wire specifically designed for use in low-voltage circuits in automobiles. With standard insulation thickness, this wire is easy to strip and cut, facilitating the installation process and ensuring efficiency in automotive wiring tasks.
One of the standout features of this wire is its excellent flame retardant properties, which are crucial for automotive applications where safety is paramount. It has successfully passed the Single vertical combustion test, demonstrating its ability to resist combustion and meet rigorous safety standards for automotive wiring.
These wires are engineered for use in low-voltage circuits within vehicles, providing a reliable and stable connection for various automotive electrical systems. Whether used in cars, trucks, or other vehicles, the QB-C 125℃ XLPO Low-Voltage Thin-Walled Automobile Line offers a dependable solution for electrical connections in automotive applications.
The XLPO (cross-linked polyolefin) insulation of the wire provides enhanced thermal and mechanical properties, making it suitable for use in challenging automotive environments. The wire's ability to withstand temperatures up to 125℃ ensures its performance and reliability in high-temperature conditions commonly found in vehicles.
Choose the QB-C 125℃ XLPO Low-Voltage Thin-Walled Automobile Line for your automotive wiring needs, confident in its quality, safety features, and durability. Trust this wire to deliver the necessary electrical connectivity and protection for low-voltage circuits in vehicles, ensuring the proper functioning and safety of automotive electrical systems.
Company advantages
1. Established in 2001, the factory boasts over 20 years of experience in production management, ensuring a high level of expertise and efficiency.
2. Daily production meetings and weekly summary meetings are held to ensure effective communication and coordination among the team members.
3. Equipped with advanced machinery and technology, the factory is able to produce high-quality products efficiently and effectively.
4. Timely delivery is a priority for the factory, ensuring that customers receive their orders promptly and as promised.
5. Quality is guaranteed at the factory, with stringent quality control measures in place to ensure that all products meet the highest standards.
Company Details
wuxi zhonghui cable co., Ltd. is located in xishan District, wuxi city, on the shore of the beautiful Taihu Lake. lt is adjacent to shanghai-Nanjing Expressway in the north, National Highway 312 in the south, and 30 kilometers away from wuxi Airport. The geographical position is superior. great accessibility. The company was founded in May 2001, covers an area of more than 15,000 square meters, has more than 120 employees, and has more than 50 million yuan in fixed assets. lt is a professional research and development, production and sales of wires, cables, plugs and power cords. of domestic enterprises.
The company mainly produces "zhongxing" brand rubber flexible cords, energy storage cables, drag chain cables, motor lead wires, plug power cords, new energy vehicle cords, photovoltaic cords, wind energy cables and other special wires and cables. The products are widely used lt is used in electric power, wind energy cables, household appliances, industrial automation, new energy vehicles, new energy power generation , construction, lifiing machinery, power tools, water pumps, robot arm cables and other industrial and civil fields.
The power cord certifications of various countries include: VDE, INMETRO, GS, UL,ETL, ASTA, NF, CEBEC, KEMA KEUR,NEMKO, DEMKO, FIMKO, SEMKO, S+, SAA, KC, SABS, S-Mark, GCC etc.
FAQ
Q1: Where is your factory located?
A1: Our factory is located in Wuxi city,Jiangsu province.
Q2: What is your MOQ and sample term?
A2: Our MOQ is 1000pcs, we can offer you free samples, but you pls pay shipping costs.
Q3: What's the leading time?
A3: Delivery will be arranged within 1-3 weeks after advance payment
